ESP32-P4-WIFI6-POE-ETH Dev Board Based on ESP32-P4 and ESP32-C6, Supports 2.4GHz Wi-Fi 6 and BLE 5, Integrated PoE Module for Power Supply, with MIPI-CSI/DSI, Ethernet Port, USB OTG 2.0 etc.

Introduction ESP32-P4-WIFI6-POE-ETH is a multimedia development board based on ESP32-P4 and ESP32-C6, Supports Wi-Fi 6 and Bluetooth 5 (LE) wireless connectivity. It features rich Human-Machine interfaces, including MIPI-CSI (with integrated Image Signal Processor), MIPI-DSI, SPI, I2S, I2C, LED PWM, MCPWM, RMT, ADC, UART, TWAI, etc. Additionally, it supports USB OTG 2.0 HS, onboard RJ45 Ethernet port with PoE functionality. Features High-performance MCU with RISC-V 32-bit dual-core and single-core processors 128 KB HP ROM, 16 KB LP ROM, 768 KB HP L2MEM, 32 KB LP Static RAM, 8 KB TCM 32MB PSRAM in the chip's package, with onboard 32MB Nor Flash Integrated PoE module, more flexible for power supply Powerful image and voice processing capability. Provides image and voice processing interfaces including JPEG Codec, Pixel Processing Accelerator, Image Signal Processor, H264 encoder Commonly used peripherals such as MIPI-CSI, MIPI-DSI, USB 2.0 OTG, Ethernet, SDIO 3.0 TF card slot, microphone, speaker header and RTC Batt. header, etc. Adapting 2*20 GPIO headers with 28 x remaining programmable GPIOs Security features: Secure Boot, Flash Encryption, cryptographic accelerators, and TRNG. Additionally, hardware access protection mechanisms help to enable Access Permission Management and Privilege Separation Package Content ESP32-P4-WIFI6-POE-ETH x1 SH1.0 4PIN cable ~150mm x2 1217 8Ω 2W speaker x1 2.4G antenna x1 Screws pack x1 Note: Online Dev Resources and Tutorials to help you easily get started. Please feel free to contact us with any questions.

• ESP32-P4-WIFI6-POE-ETH development board, based on ESP32-P4 and ESP32-C6, high-performance MCU with RISC-V 32-bit dual-core and single-core processors, supports 2.4GHz Wi-Fi 6 and Bluetooth 5 (LE)
• Featuring 32MB PSRAM in the chip's package, with onboard 32MB Nor Flash, 128 KB HP ROM, 16 KB LP ROM, 768 KB HP L2MEM, 32 KB LP Static RAM, 8 KB TCM
• Integrated PoE module, supports PoE power supply. Rich human-machine interfaces such as MIPI-CSI, MIPI-DSI, USB 2.0 OTG, 100Mbps RJ45 Ethernet port, SDIO 3.0 TF card slot, onboard microphone, speaker header and RTC Batt. header, etc.
• Powerful image and voice processing capability. Provides image and voice processing interfaces including JPEG Codec, Pixel Processing Accelerator, Image Signal Processor, H264 encoder
• Security features: Secure Boot, Flash Encryption, Cryptographic Accelerators, and TRNG. Additionally, hardware access protection mechanisms help to enable Access Permission Management and Privilege Separation
